Thuren front coils

Post by stubiePW » Tue Oct 27, 2015 5:32 pm

I've been reading and do not want to beat a dead horse, but I want to bring up the front end a bit (no spacers). I don't have the $$ for shocks just yet. I was thinking 3" coils from Thuren. Or should I just go with the 2"?

Like I said, I know it's been covered. I have a 2012 stock minus the thuren control arms. I am hoping to keep the rub on the sway bar down a bit more.

Thanks guys

2011RPW
250_Posts
250_Posts
Posts: 278
Joined: Thu Oct 24, 2013 9:22 pm
Model Year: 2011
Location: Harper, TX

Thuren front coils

Post by 2011RPW » Wed Oct 28, 2015 12:07 am

2" coils will should level you out (I'm not 100% on this, I've never seen a Hemi/PW with the 2" coils), 3" will require shackles in the back.
I put 3" coils on mine, and I've got the shackles out back, as well, on highest setting. Well worth the money!

Keep in mind, an adjustable track bar is also a must-do, as well.
2011
Thuren 3" Suspension, 37' Toyo R/T's, S&B, Flowmaster, Diablo Trinity, N-Fab steps (junk), 31" LED Light Bar, Replacement Bumpers, debadged.

User avatar
stubiePW
500_Posts
500_Posts
Posts: 581
Joined: Mon Nov 12, 2012 7:45 pm

Re: Thuren front coils

Post by stubiePW » Wed Oct 28, 2015 7:48 am

Did you replace the shocks? Just curious. I guess I need to save up some money and make that happen!

User avatar
leo72987
250_Posts
250_Posts
Posts: 492
Joined: Tue Nov 05, 2013 1:38 pm
Location: Ware, MA

Re: Thuren front coils

Post by leo72987 » Wed Oct 28, 2015 10:08 am

First things first 2011RPW sexy truck!! As to the 2 inch Thuren coils see below with the estimated lift heights I got these numbers from Don and cjc offroad.
-2.5" of lift on 3rd gen Hemis
-2.5" of lift on 2nd gen diesels
-3" lift on 2nd gen gas
-2" of lift on 3rd gen diesels

http://www.cjcoffroad.com/Thuren-2-Soft ... p/tf2c.htm

With that being said I have no info on 4th gen's just that they are heavier... Carli 3 inch and thuren 2 inch coils apparently give power wagons about an inch lift over stock on average as the argument has been that Wagons come with roughly a 2inch lift from Factory with a 1/2 lift from bigger 33 inch tires.. At least this was the rule of thumb with us 3rd gen guys... The Thuren 3 inch coils would give you about 4 inches of lift making a new track bar mandatory. You could probably stick with stock shocks if you used the 2 inch coils. Anything bigger and your shocks will act like limiting straps LOL.
2005 Wagon Standard Cab Auto,Bilstein 5100's,White Knuckle Sliders,Dodge Offroad Diff covers,Cooper St Maxx's stock size, Hardwired lockers,Evo manual sway bar disconnect conversion, DT Pro Fab Sway Bar links

2wagons1driveway
2000_Posts
2000_Posts
Posts: 2970
Joined: Wed Jan 16, 2013 6:55 pm
Location: ontario canada

Re: Thuren front coils

Post by 2wagons1driveway » Wed Oct 28, 2015 11:22 am

Agreed 3" Thuren coils and you should run a new track bar. 3.5-3.75" of lift on a fourth gen truck depending on bumper weight.


Sent from Canada
if guns kill people
pencils mispell words
cars make people drive drunk
and spoons made rosie o'donnel fat

"The one thing you realize when you aquire your trade standard is you realistically don't know Anything"

User avatar
Kenadian
50_Posts
50_Posts
Posts: 70
Joined: Sun Dec 22, 2013 1:23 am
Model Year: 2013

Re: Thuren front coils

Post by Kenadian » Fri Oct 30, 2015 6:54 pm

I'm running the Thuren 3" coils adjustable track bar rear shackles boogie bumps and overland shocks annnnd the high clearance control arms. Fit 37" tires with ease. And a heavy ass bumper. Sits pretty good I am on mid height on my shackles

I like to break things !!!

User avatar
2011TXPowerWagon
500_Posts
500_Posts
Posts: 509
Joined: Fri Aug 08, 2014 5:07 pm
Model Year: 2011
Location: Edinburg, Texas

Re: Thuren front coils

Post by 2011TXPowerWagon » Sun Nov 01, 2015 12:55 pm

Kenadian wrote:I'm running the Thuren 3" coils adjustable track bar rear shackles boogie bumps and overland shocks annnnd the high clearance control arms.
That is the exact setup I am planning, well minus the boogies. If buying in stages would you recommend the arms first?
"A government that robs Peter to pay Paul can always depend on the support of Paul."

-George Bernard Shaw

AllanDickerson
50_Posts
50_Posts
Posts: 99
Joined: Thu Jan 09, 2014 3:19 pm
Location: South Carolina

Re: Thuren front coils

Post by AllanDickerson » Sun Nov 01, 2015 1:55 pm

I know this is a 4th gen thread but I just put 3 inch coils and track bar on my 05 and I'm sitting about a 3/8 above level.

User avatar
Kenadian
50_Posts
50_Posts
Posts: 70
Joined: Sun Dec 22, 2013 1:23 am
Model Year: 2013

Re: Thuren front coils

Post by Kenadian » Tue Nov 10, 2015 8:56 pm

2011TXPowerWagon wrote:
Kenadian wrote:I'm running the Thuren 3" coils adjustable track bar rear shackles boogie bumps and overland shocks annnnd the high clearance control arms.
That is the exact setup I am planning, well minus the boogies. If buying in stages would you recommend the arms first?
Yes arms first. Then you can run the 37" at stock height then add as you go. To get more clearance and better ride.


I like to break things !!!

User avatar
Kenadian
50_Posts
50_Posts
Posts: 70
Joined: Sun Dec 22, 2013 1:23 am
Model Year: 2013

Re: Thuren front coils

Post by Kenadian » Tue Nov 10, 2015 8:57 pm

That's what I did with mine

I like to break things !!!

2011RPW
250_Posts
250_Posts
Posts: 278
Joined: Thu Oct 24, 2013 9:22 pm
Model Year: 2011
Location: Harper, TX

Re: Thuren front coils

Post by 2011RPW » Tue Nov 10, 2015 10:12 pm

AllanDickerson wrote:I know this is a 4th gen thread but I just put 3 inch coils and track bar on my 05 and I'm sitting about a 3/8 above level.
Measuring from Bumpstops? Or fenders? Fender measurements aren't accurate, or so I've been told.
2011
Thuren 3" Suspension, 37' Toyo R/T's, S&B, Flowmaster, Diablo Trinity, N-Fab steps (junk), 31" LED Light Bar, Replacement Bumpers, debadged.

AllanDickerson
50_Posts
50_Posts
Posts: 99
Joined: Thu Jan 09, 2014 3:19 pm
Location: South Carolina

Re: Thuren front coils

Post by AllanDickerson » Tue Nov 10, 2015 10:21 pm

From the fenders. That's where I see the difference so I measured there

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3657
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Thuren front coils

Post by olyelr » Tue Nov 10, 2015 10:42 pm

Yeah fender measurements are not always the best place to measure from, but they are a good start.

I have always figured a truck looks "level" if the lower portion of the body between the front and rear tires is at a level plane, or just a touch lower in the front. My jeep is setup this way and the front fenders are an inch higher than the backs. But it looks level.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes - 35” AT3W - TazerRAM

:patriot:

AllanDickerson
50_Posts
50_Posts
Posts: 99
Joined: Thu Jan 09, 2014 3:19 pm
Location: South Carolina

Re: Thuren front coils

Post by AllanDickerson » Wed Nov 11, 2015 4:31 pm

I'll have to try that and see where I'm at.

AllanDickerson
50_Posts
50_Posts
Posts: 99
Joined: Thu Jan 09, 2014 3:19 pm
Location: South Carolina

Re: Thuren front coils

Post by AllanDickerson » Fri Nov 20, 2015 5:40 pm

I measured the lower portion of the body. I'm about 3/8 high in the front with thuren 3 inch coils on my 3rd gen with a stock bumper. It still tows great, I towed a boat yesterday on a double axle trailer weighing about 7000 pounds.
