Kill-switch for electronic nannies

Post by olyelr » Wed Sep 28, 2016 1:36 pm

I'm starting off with a few questions so bare with me...

Does anybody know of a good source for diagrams of the wiring in our trucks? When searching on-line I have seen links to "the holy grail" of diagrams, but they are always broken links :doh:

Also, do the electronic nannies in these new PW's cause issues when using the truck off road in 2WD or 4HI (I'm assuming most of the nannies are shut off in 4LO)? If it is anything like my JK was it is a huge PITA, but I admit I havnt done much wheeling with my new truck yet (well, no snow or no 4HI yet at all).




With my JK one of my most favorite mods I did was installed a kill-switch for all of the stupid nannies. I find myself 2WD wheeling or 4HI wheeling from time to time, and that crap always kicking on drove me nuts. I simply installed a switch on one of the wires (violet with light blue tracer) going to the yaw sensor under the center council. When the switch was used it completely shut off all nannies; traction control stuff, antilock brakes, all that stuff. I am looking at doing something like this to my wagon, just a little sketched out about guess-cutting wires on a $60K truck just to see if it may work.

I took my center council/seat tray off last night and there appears to be one of those same type of yaw sensors there, just like the Jeep. I would just like to look a little further into exactly what sensor this is, and possibly what the wires are for that are coming and going from it.

Any input is greatly appreciated.

:winchmob:
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
cruz
500_Posts
500_Posts
Posts: 996
Joined: Sat May 26, 2012 11:36 am
Location: Santa Cruz, CA

Re: Kill-switch for electronic nannies

Post by cruz » Wed Sep 28, 2016 1:58 pm

olyelr wrote:... I am looking at doing something like this to my wagon, just a little sketched out about guess-cutting wires on a $60K truck just to see if it may work...
I say go for it... :lol:
Attachments
2005 Power Wagon

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Wed Sep 28, 2016 2:09 pm

Funny cruz. If it didnt work it certainly wouldnt be hard to re-connect the wire I cut... I just worry about frying some type of sensor or something haha.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

RustyPW
2000_Posts
2000_Posts
Posts: 4234
Joined: Thu May 24, 2012 4:23 pm
Model Year: 2008
Location: Brownsville Pa.

Re: Kill-switch for electronic nannies

Post by RustyPW » Wed Sep 28, 2016 2:28 pm

In my Nismo. I had to splice in a switch to the Yaw sensor to eliminate the nannies for doing trackdays. You had to do the samething on your jeep. Think you may be on to something with the PW.
PWOC #53
2008 POWER WAGON RC
Mods to the PW; Nerffed Mopar RockRails, Wheel Well Liners, Bushwacker Pocket Fender Flairs, Garvmin dezl 560LMT GPS, Power Wagon Winch Kit, Line X Ultra Bed Liner, PIAA Headlight Bulbs, PIAA 580 Driving Lights (135 watt), PIAA 520 Fog Lights (135 watt), PIAA 520 ATP Off-Road Lights (135 watt), Locker Bypass, Modifed Rockcrusher Diff Covers, Mopar Utility Bed Rails and Tool Box, Warn Winch Wireless Remote Control, "el-cheapo" Inclinometer, Airaid CAI, Winch TPS Bypass, 35" Toyo's, Mopar Spare Tire Lock, 'T' Steering Linkage, Modifed PSC Steering Brace, P3 Brake Controller, Modifed Fusion "mall crawler" rear bumper , PIAA 1500 Back-Up Lights, 1Ton HEMI Tranny Cooler, Leer 100XR Bed Cap, Factory Tow Mirrors, CenterLine Rims 17x9-5.25 BS, Mag-Hytec Tranny Pan, AutoMeter Gauges, PSC Extreme Hydro Assist Steering, Carli G2 Track Bar, Carli Ball-Joints, Dynatrac FreeSpin Hubs, Snorkel, RCV Axles, EBC Pads & Rotors, Aluminess Front Bumper, 14,000 lb Pul-Pal, 60" Extreme Hi-lift Jack, and more riggin' equipment, Carli Long Travel Air Bags, Bilstein 7100 Shocks - Carli Valving, Carli Control Arms, Thuren 3" SoftRide Springs, Thuren Rear Shackles, MagnaFlow Muffler, Crown Stainless Brake Lines, MORE STUFF COMIN'.

Moab '10, '12, '14.
Rausch Creek Spring-Fall '11, Spring '12, Summer '13, Summer '14, Summer '15, Summer '16, Summer '17, Summer '18,
Russ NRA Benefactor Member

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Wed Sep 28, 2016 2:43 pm

RustyPW wrote:In my Nismo. I had to splice in a switch to the Yaw sensor to eliminate the nannies for doing trackdays. You had to do the samething on your jeep. Think you may be on to something with the PW.
Well I admit, I am not even sure if the PW's system is all that intrusive or annoying (where is snowsled :mrgreen: )... I just havent got to use the truck enough yet. But if it is anything like my Jeep was, then I want that shit shut off when I am off road.

I really liked all of the features when using the Jeep on the main roads. The worked very well. I never drove on the main roads with the nannies not in use. But, that junk isnt designed for off road use.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
huntinguy
Posts: 43
Joined: Mon Aug 11, 2014 9:31 pm
Model Year: 2014
Location: Western Nebraska

Re: Kill-switch for electronic nannies

Post by huntinguy » Wed Sep 28, 2016 11:45 pm

There is a yaw sensor under the center console. You can put a switch in that circuit. Another way to do it is to switch the circuit for the abs pump.

Sent from my XT1080 using Tapatalk
2014 Powerwagon. Stock for now.
1989 Dodge W-250 Cummins. 4" lift, 35's, crossover steering, power mods.

User avatar
adeluca73
2000_Posts
2000_Posts
Posts: 2158
Joined: Mon May 19, 2014 11:56 pm
Model Year: 2014
Location: The Pentagon, VA

Re: Kill-switch for electronic nannies

Post by adeluca73 » Thu Sep 29, 2016 12:15 am

Easier way Olyeler is to pull the ABS fuse, which guarantees none of the electronic controls will activate & then you don't have to cut wires or install another switch. I'll run out & check this weekend and tell you which # it is.
2014 Ram PW SLT: 1st year of the Best Gen
<Build Thread>

User avatar
Chromolykid
50_Posts
50_Posts
Posts: 210
Joined: Sun Oct 25, 2015 11:05 pm
Model Year: 2014
Location: Phelan, CA
Contact:

Re: Kill-switch for electronic nannies

Post by Chromolykid » Thu Sep 29, 2016 12:45 am

Or wire a simple toggle switch to interrupt the ABS fuse. Dash will light up but you'll be nanny-free and can likely do it on the fly. Re-engaging normal operation would probably require restarting the truck, I'm guessing. Give it a shot and let us know?

I haven't experienced anything drastic enough to merit wiring a killswitch yet, the only issue I ran across was forgetting to hold the TCS button in 4HI before entering a large uphill sand wash that required a minimum speed of about 25 to stay on top... The ESC kept activating as I attempted to get out of the grooves and would slow me down to about 27, nearly getting me stuck several times. Anything under 20 and the ESC can be deactivated, for those who don't know. My mistake, won't happen again.

Or as Snowsled would tell the story: "MY POSER WAGON TRIED TO KILL ME." :roll:
“Furiosa”
2016 Power Wagon
White Knuckle Sliders
Walker Evans Wheels in 35” BFG KO2’s
DOR Steering Brace
Thuren Stage 1 KING 2.5’s
Thuren Coils Front & Rear
Thuren Track Bars Front & Rear
AEV Procal
Carli Front Diff Guard/Purple Cranium Half Spider Rear
Putco LED Headlights & Foglights
Custom Fender Flares and Grill

User avatar
Reloaderguy
2000_Posts
2000_Posts
Posts: 2050
Joined: Tue Feb 09, 2016 8:06 am
Model Year: 2016
Location: Central Oregon

Re: Kill-switch for electronic nannies

Post by Reloaderguy » Thu Sep 29, 2016 3:02 am

Some of the tuners allow you to disable TCS.
Best Year Power Wagon

RustyPW
2000_Posts
2000_Posts
Posts: 4234
Joined: Thu May 24, 2012 4:23 pm
Model Year: 2008
Location: Brownsville Pa.

Re: Kill-switch for electronic nannies

Post by RustyPW » Thu Sep 29, 2016 5:41 am

In my Nismo. I have to turn the car off, flip the switch and restart for everything to go back to normal.
PWOC #53
2008 POWER WAGON RC
Mods to the PW; Nerffed Mopar RockRails, Wheel Well Liners, Bushwacker Pocket Fender Flairs, Garvmin dezl 560LMT GPS, Power Wagon Winch Kit, Line X Ultra Bed Liner, PIAA Headlight Bulbs, PIAA 580 Driving Lights (135 watt), PIAA 520 Fog Lights (135 watt), PIAA 520 ATP Off-Road Lights (135 watt), Locker Bypass, Modifed Rockcrusher Diff Covers, Mopar Utility Bed Rails and Tool Box, Warn Winch Wireless Remote Control, "el-cheapo" Inclinometer, Airaid CAI, Winch TPS Bypass, 35" Toyo's, Mopar Spare Tire Lock, 'T' Steering Linkage, Modifed PSC Steering Brace, P3 Brake Controller, Modifed Fusion "mall crawler" rear bumper , PIAA 1500 Back-Up Lights, 1Ton HEMI Tranny Cooler, Leer 100XR Bed Cap, Factory Tow Mirrors, CenterLine Rims 17x9-5.25 BS, Mag-Hytec Tranny Pan, AutoMeter Gauges, PSC Extreme Hydro Assist Steering, Carli G2 Track Bar, Carli Ball-Joints, Dynatrac FreeSpin Hubs, Snorkel, RCV Axles, EBC Pads & Rotors, Aluminess Front Bumper, 14,000 lb Pul-Pal, 60" Extreme Hi-lift Jack, and more riggin' equipment, Carli Long Travel Air Bags, Bilstein 7100 Shocks - Carli Valving, Carli Control Arms, Thuren 3" SoftRide Springs, Thuren Rear Shackles, MagnaFlow Muffler, Crown Stainless Brake Lines, MORE STUFF COMIN'.

Moab '10, '12, '14.
Rausch Creek Spring-Fall '11, Spring '12, Summer '13, Summer '14, Summer '15, Summer '16, Summer '17, Summer '18,
Russ NRA Benefactor Member

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Thu Sep 29, 2016 7:01 am

Yeah i guess if pulling a fuse worked i could do that too. The abs fuse will shut all that stuff off?

But really, cutting a single wire and putting a switch on it doesnt bother me at all, as long as it works.

In my jeep to get the system back on, the vehicle had to be shut off and then restarted.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
Low_Sky
500_Posts
500_Posts
Posts: 791
Joined: Fri May 01, 2015 7:12 pm
Model Year: 2015
Location: Eagle River, Alaska

Re: Kill-switch for electronic nannies

Post by Low_Sky » Thu Sep 29, 2016 11:31 am

The braking component of ESC runs off of the ABS pump, and without the ability to brake the whole system apparently shuts off. I believe I went looking for the fuse once, but the map printed inside the fuse block didn't match the table that was printed in my owner's manual and I didn't have time to go experimenting to find the right fuse.


Sent from my iPhone using Tapatalk
John
Alaska
2015 PW on 2.5" Thuren Kings
My build thread

TwinStick
2000_Posts
2000_Posts
Posts: 4145
Joined: Mon May 28, 2012 7:58 pm
Model Year: 2008

Re: Kill-switch for electronic nannies

Post by TwinStick » Thu Sep 29, 2016 1:44 pm

Also, they usually put more than one thing on a fuse. So, if you disable it, something else may not work either. May throw a code/s. Most certainly it will void the warranty if dealer finds it, or the computer logs something was disabled & they see that.
In WNY State. 2008 Red QC PW G56. No lift yet, stock size tires. It pulls an 18' 2016 Starcraft AR One Extreme, 3500 lbs.
Load Pro 35 helper springs. 2015 A.R.E. MX Series custom cap. PCP front diff cover protector. Mag-Hytec 6 qt rear diff cover. K&N replacement air filter only. Dual grounded throttle body. Winch TPC bypass. Fab Four rear bumper. DURA BAK lined rocker protection. And a bunch of new front end stuff.

G-56 Gear ratios: 1st) 6.29:1 2nd) 3.48:1 3rd) 2.10:1 4th) 1.38:1 5th) 1.0:1 6th) 0.79:1 Rev 6.29:1 --- = 78.01613:1 Crawl Ratio
-------------------------5.94:1--------3.28:1-------1.98:1-------1.31:1-------1.0:1-------0.74:1-----5.42:1 ---- = 73.675:1
545RFE----------------3.0:1---------1.67:1--------1.0:1--------0.75:1-------0.67:1------------------3.0:1 -------=37.21:1

2013+ 32.47 crawl ratio...............Can you see the trend ??????????????

User avatar
Mike-H
50_Posts
50_Posts
Posts: 125
Joined: Sat May 30, 2015 10:38 pm
Model Year: 2013
Location: Central, Az

Re: Kill-switch for electronic nannies

Post by Mike-H » Sat Oct 01, 2016 12:36 pm

The guys on this forum figured it out. http://dodgetrucksxtreme.com/index.php?topic=11468.0 I did read somewhere else the newer trucks were having issues using this technique. Apparently the dash was shutting off with the switch. I can't seem to find that link now.

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Oct 02, 2016 9:26 am

Well I'll be go to heck. Thanks for the link, I will surely check it out!
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
Reloaderguy
2000_Posts
2000_Posts
Posts: 2050
Joined: Tue Feb 09, 2016 8:06 am
Model Year: 2016
Location: Central Oregon

Re: Kill-switch for electronic nannies

Post by Reloaderguy » Sat Dec 17, 2016 7:05 pm

olyelr wrote:
I took my center council/seat tray off last night and there appears to be one of those same type of yaw sensors there, just like the Jeep. I would just like to look a little further into exactly what sensor this is, and possibly what the wires are for that are coming and going from it.

Any input is greatly appreciated.

:winchmob:
Can you just clip the negative on the sensor and run wiring through a SPST switch?
Best Year Power Wagon

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Dec 18, 2016 12:52 am

Reloaderguy wrote:
olyelr wrote:
I took my center council/seat tray off last night and there appears to be one of those same type of yaw sensors there, just like the Jeep. I would just like to look a little further into exactly what sensor this is, and possibly what the wires are for that are coming and going from it.

Any input is greatly appreciated.

:winchmob:
Can you just clip the negative on the sensor and run wiring through a SPST switch?
No idea! Wth is a SPST switch :lol:

I am horrible with wiring.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
adeluca73
2000_Posts
2000_Posts
Posts: 2158
Joined: Mon May 19, 2014 11:56 pm
Model Year: 2014
Location: The Pentagon, VA

Re: Kill-switch for electronic nannies

Post by adeluca73 » Sun Dec 18, 2016 12:57 am

1-way switch--single pole single throw
2014 Ram PW SLT: 1st year of the Best Gen
<Build Thread>

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Dec 18, 2016 12:58 am

TwinStick wrote:Also, they usually put more than one thing on a fuse. So, if you disable it, something else may not work either. May throw a code/s. Most certainly it will void the warranty if dealer finds it, or the computer logs something was disabled & they see that.

Well get this. I now know that when the abs isnt working in a 13+ cummins truck, niether does the 4x4 :doh: wonder if that is the same for a pw.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Dec 18, 2016 1:00 am

adeluca73 wrote:1-way switch--single pole single throw

That is all i put in the jeep and all was good. But...
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
Reloaderguy
2000_Posts
2000_Posts
Posts: 2050
Joined: Tue Feb 09, 2016 8:06 am
Model Year: 2016
Location: Central Oregon

Re: Kill-switch for electronic nannies

Post by Reloaderguy » Sun Dec 18, 2016 1:30 pm

olyelr wrote:
adeluca73 wrote:1-way switch--single pole single throw

That is all i put in the jeep and all was good. But...
Show me a picture. I have an SPST rocker and I'm willing to chop-fu for the good of the hive. My thought is a SPST switch that breaks the negative instead of running positive power. Run positive power to the rocker for cab lighting function and when the switch is activated. No actual power from the sensor though. Thoughts?
Best Year Power Wagon

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Dec 18, 2016 2:32 pm

Here is a small writeup i did on Jk forum for my jeep. There are a few pics in there.

http://www.jk-forum.com/forums/jk-write ... up-260247/

I would LOVE to do this to the pw.
2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
Reloaderguy
2000_Posts
2000_Posts
Posts: 2050
Joined: Tue Feb 09, 2016 8:06 am
Model Year: 2016
Location: Central Oregon

Re: Kill-switch for electronic nannies

Post by Reloaderguy » Sun Dec 18, 2016 2:46 pm

olyelr wrote:Here is a small writeup i did on Jk forum for my jeep. There are a few pics in there.

http://www.jk-forum.com/forums/jk-write ... up-260247/

I would LOVE to do this to the pw.
Is that what the PW sensor looks like?
Best Year Power Wagon

User avatar
olyelr
2000_Posts
2000_Posts
Posts: 3243
Joined: Sun Dec 07, 2014 9:00 pm
Model Year: 2016
Location: Kewadin, MI

Re: Kill-switch for electronic nannies

Post by olyelr » Sun Dec 18, 2016 4:23 pm

No not really. But there is lots of wires coming from it.



2016 Ram Power Wagon Laramie - Granite Crystal Metallic - Ramboxes :patriot:

User avatar
Reloaderguy
2000_Posts
2000_Posts
Posts: 2050
Joined: Tue Feb 09, 2016 8:06 am
Model Year: 2016
Location: Central Oregon

Re: Kill-switch for electronic nannies

Post by Reloaderguy » Sun Dec 18, 2016 4:40 pm

There is another sensor in there...if you unplug it your computer goes all unhappy.
Best Year Power Wagon

Post Reply
